VVA3 7,2kV/4A 004221104

Specifikacija

Koda izdelka:
004221104
Opis:
VVA3 7,2kV/4A
Nazivni minimalni odklopni tok (A):
20
Hladna upornost (mΩ):
370
Nazivni tok (A):
4
Tip:
Nova VVA brez udarne igle
Velikost:
192
Karakteristika:
Other
Nazivna AC napetost (V):
7200
Indikator:
Brez
AC Izklopna zmogljivost (kA):
63
Izgubna moč (W):
9
Aplikacije:
Zaščita transformatorja, zaščita motorja, zaščita kondenzatorske baterije, vgradnja v obročno glavno enoto

Dokumenti

Produkt

EAN koda izdelka
3838895911593
Teža izdelka
1.2 kg
Carinska tarifa
85351000

Osnovno pakiranje

Osnovno pakiranje
1
EAN koda osnovnega pakiranja
3838895911593
Teža osnovnega pakiranja
1.2 kg
Volumen osnovnega pakiranja
5.14

Transportno pakiranje

Pakirna količina
3
EAN koda odpremnega pakiranja
3838895911609
Teža odpremnega pakiranja
4.22 kg
Volumen pakirne embalaže
15.42
Odpremna količina
180
Volumen paletnega pakiranja
925.2

Slike in diagrami

Programska oprema

Konfigurator Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
004221104Fuse link, VVA3 7,2kV/4AVVHigh voltage fuse-links7,2 kV192 mm192 mmVVAFuse links for medium voltageVVAVVA3 7,2KV/4ARated current 4AType NEW VVA without strikerSize 192Characteristics OtherRated AC voltage 7200VIndicator WithoutBreaking capacity AC 63kAPower dissipation 9WApplication transformer protection, motor protection, capacitor bank protection, installation in ring main unitRated minimum breaking current 20ACold resistance 370mΩFuse link VVA3 NEW VVA without striker 192 4A 7200VFuse link VVA3 NEW VVA without striker 192 4A 7200V
