Modularni kontaktorji so kompaktne in vsestranske naprave, namenjene daljinskemu krmiljenju in avtomatizaciji električnih tokokrogov. Posebej primerni so za vgradnjo v razdelilne omarice v različnih okoljih – stanovanjskih, poslovnih in industrijskih.

002464084

Slika RD 32-20 24V AC/DC

RD 32-20 24V AC/DC Modularni kontaktor

Zaloga status Po naročilu

ETI koda:: 002464084
Opis tipa:: AC/DC
Nazivni delovni tok Ie AC-1/AC-7a:: 32 A
Nazivna delovna napetost (V AC):: 230 V
Nazivna krmilna napetost Uc (V AC): 230:: 24 V
Tip toka:: AC, DC
Nazivna frekvenca:: 50/60 Hz
Št. NO kontaktov:: 2
Funkcija:: Modularni kontaktorji
Kataloška skupina:: RD

Izjava

Produkt

Neto teža izdelka: 0,13 kg
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 10 pcs
EAN code for a basic packaging: 3838400137593
Basic packaging weight: 1,3 kg
Basic Packaging Dimensions Height: 74 mm
Basic Packaging Dimensions Width: 93 mm
Basic Packaging Dimensions Depth: 180 mm
Basic packaging volume: 1,239 dm³

Transportna embalaža

Transport packaging quantity: 80 pcs
EAN code for a transport packaging: 3838400137586
Transport packaging weight: 10,4 kg
Transport Packaging Dimensions Height: 165 mm
Transport Packaging Dimensions Width: 195 mm
Transport Packaging Dimensions Depth: 445 mm
Transport packaging volume: 14,318 dm³
Pallet quantity: 3.840 pcs
Customs tariff: 85364900

Voltage type (excitation voltage): AC
Voltage type (operating voltage): AC/DC
Degree of protection (IP): IP20
Number of contacts as normally open contact: 2
Rated operation current: 32 A
Rated excitation voltage(Min): 230 V
Rated operating voltage(Min): 24 V
Rated operating voltage(Max): 24 V
Rated excitation voltage(Max): 230 V

ETIM klasifikacija – različica 9.0
