NHS2XL gPV 250A/1100V DC Talilni vložek

Zaloga status Po naročilu

ETI koda:: 004110423
Tip varovalke:: NH-S
Velikost:: NH2XL
Nazivni tok:: 250 A
Karakteristika:: gPV
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna enosmerna napetost:: 1100 V
DC Izklopna zmogljivost:: 10 kA
L/R:: 5 ms
Izgubna moč (0,7xIn):: 17,9 W
Izgubna moč:: 46 W
Talilni Joulov integral (A2s):: 85.260
Skupni Joulov integral (A2s):: 117.400
Standardi:: IEC 60269-6
Aplikacije:: Talilni vložki za DC aplikacije

Pribor

Produkt

Neto teža izdelka: 1.050 g
Net width: 55 mm
Net height: 198 mm
Net depth: 59 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895504276
Basic packaging weight: 1,05 kg
Basic Packaging Dimensions Height: 0,064 m
Basic Packaging Dimensions Width: 0,222 m
Basic Packaging Dimensions Depth: 0,089 m
Basic packaging volume: 0,001 m³

Transportna embalaža

Transport packaging quantity: 12 pcs
EAN code for a transport packaging: 3838895534488
Transport packaging weight: 12,95 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 624 pcs
Customs tariff: 85351000

Voltage type: DC
Fuse construction type according to IEC 60269: 2XL
Power loss at rated current: 46 W
Rated switching capacity DC: 10 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 250 A
Rated voltage DC: 1.100
Utilization category: gPV (photovoltaic protection)
