NHU1XL gPV 160A/1500V DC UL Talilni vložek

Zaloga status Po naročilu

ETI koda:: 004110610
Tip varovalke:: NH-U
Velikost:: NH1XL
Nazivni tok:: 160 A
Karakteristika:: gPV
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna enosmerna napetost:: 1500 V
DC Izklopna zmogljivost:: 30 kA
L/R:: 3 ms
Izgubna moč (0,7xIn):: 13,2 W
Izgubna moč:: 30 W
Talilni Joulov integral (A2s):: 19.000
Skupni Joulov integral (A2s):: 48.000
UL certifikat:: E347771
Standardi:: IEC 60269-6, UL 248-19
Aplikacije:: Talilni vložki za DC aplikacije

Pribor

Produkt

Neto teža izdelka: 950 g
Net width: 51 mm
Net height: 198 mm
Net depth: 51 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895737292
Basic packaging weight: 0,95 kg
Basic Packaging Dimensions Height: 0,055 m
Basic Packaging Dimensions Width: 0,205 m
Basic Packaging Dimensions Depth: 0,076 m
Basic packaging volume: 0,001 m³

Transportna embalaža

Transport packaging quantity: 16 pcs
EAN code for a transport packaging: 3838895737308
Transport packaging weight: 15,55 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 832 pcs
Customs tariff: 85351000

Voltage type: DC
Fuse construction type according to IEC 60269: 1XL
Power loss at rated current: 30 W
Rated switching capacity DC: 30 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 160 A
Rated voltage DC: 1.500
Utilization category: gPV (photovoltaic protection)
