NH0 gR 125A/750V DC Talilni vložek

Zaloga status Na zalogi

ETI koda:: 004110507
Tip varovalke:: NH
Velikost:: NH0
Nazivni tok:: 125 A
Karakteristika:: gR
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna enosmerna napetost:: 750 V
DC Izklopna zmogljivost:: 20 kA
L/R:: 2 ms
Izgubna moč:: 22 W
Talilni Joulov integral (A2s):: 6.300
Skupni Joulov integral (A2s):: 14.090
Standardi:: IEC 60269-4
Aplikacije:: Talilni vložki za DC aplikacije

Pribor

Produkt

EAN code for a single product: 3838895757825
Neto teža izdelka: 290 g
Net width: 29 mm
Net height: 124 mm
Net depth: 59,5 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 3 pcs
EAN code for a basic packaging: 3838895600367
Basic packaging weight: 0,905 kg
Basic Packaging Dimensions Height: 0,066 m
Basic Packaging Dimensions Width: 0,093 m
Basic Packaging Dimensions Depth: 0,138 m
Basic packaging volume: 0,001 m³

Transportna embalaža

Transport packaging quantity: 45 pcs
EAN code for a transport packaging: 3838895600374
Transport packaging weight: 13,919 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 2.340 pcs
Customs tariff: 85361090

Voltage type: DC
Fuse construction type according to IEC 60269: NH0
Power loss at rated current: 22 W
Rated switching capacity DC: 20 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 125 A
Rated voltage DC: 750
Utilization category: gR (general purpose semiconductor protection)

ETIM klasifikacija – različica 9.0
