NH1C gR 40A/750V DC Talilni vložek

ETI koda:: 004110512
Tip varovalke:: NH
Velikost:: NH1C
Nazivni tok:: 40 A
Karakteristika:: gR
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna enosmerna napetost:: 750 V
DC Izklopna zmogljivost:: 20 kA
L/R:: 2 ms
Izgubna moč:: 8,8 W
Talilni Joulov integral (A2s):: 135
Skupni Joulov integral (A2s):: 650
Standardi:: IEC 60269-4
Aplikacije:: Talilni vložki za DC aplikacije

Pribor

Produkt

EAN code for a single product: 3838895757856
Neto teža izdelka: 300 g
Net width: 29 mm
Net height: 136 mm
Net depth: 64,5 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 3 pcs
EAN code for a basic packaging: 3838895600442
Basic packaging weight: 0,935 kg
Basic Packaging Dimensions Height: 0,066 m
Basic Packaging Dimensions Width: 0,093 m
Basic Packaging Dimensions Depth: 0,138 m
Basic packaging volume: 0,001 m³

Transportna embalaža

Transport packaging quantity: 45 pcs
EAN code for a transport packaging: 3838895600459
Transport packaging weight: 14,369 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 2.340 pcs
Customs tariff: 85361050

Voltage type: DC
Fuse construction type according to IEC 60269: NH1C
Power loss at rated current: 8,8 W
Rated switching capacity DC: 20 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 40 A
Rated voltage DC: 750
Utilization category: gR (general purpose semiconductor protection)
