004304228

NH2 UQ01 aR 630A/1000V Talilni vložek

Zaloga status Na zalogi

ETI koda:: 004304228
Tip varovalke:: NH
Velikost:: NH2
Nazivni tok:: 630 A
Karakteristika:: aR
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna AC napetost:: 1000 V
Nazivna enosmerna napetost:: 800 V
AC Izklopna zmogljivost:: 200 kA
Izgubna moč:: 108 W
Skupni Joulov integral (A2s):: 600.000
Standardi:: IEC 60269-4
Aplikacije:: Za zaščito polprevodniških naprav

Pribor

Produkt

Neto teža izdelka: 880 g
Net width: 60 mm
Net height: 150 mm
Net depth: 72,5 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895466215
Basic packaging weight: 0,93 kg
Basic Packaging Dimensions Height: 0,152 m
Basic Packaging Dimensions Width: 0,075 m
Basic Packaging Dimensions Depth: 0,062 m
Basic packaging volume: 0,001 m³

Transportna embalaža

Transport packaging quantity: 16 pcs
EAN code for a transport packaging: 3838895713234
Transport packaging weight: 15,23 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 832 pcs
Customs tariff: 85361090

Rated switching capacity AC: 200 kA
Voltage type: AC/DC
Fuse construction type according to IEC 60269: NH2
Rated voltage AC: 1.000
Power loss at rated current: 108 W
Type of fuse status indicator: Top fuse status indicator
Rated current: 630 A
Rated voltage DC: 800
Utilization category: aR (accompanied semiconductor protection)

ETIM klasifikacija – različica 9.0
