004723116

NHS1/110 UQ2 gR 160A/690V Talilni vložek

Zaloga status Po naročilu

ETI koda:: 004723116
Tip varovalke:: NH-S
Velikost:: NH1
Nazivni tok:: 160 A
Karakteristika:: gR
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna AC napetost:: 690 V
AC Izklopna zmogljivost:: 200 kA
Izgubna moč:: 23,8 W
Skupni Joulov integral (A2s):: 23.000
Standardi:: IEC 60269-4
Aplikacije:: Za zaščito polprevodniških naprav

Pribor

Produkt

Neto teža izdelka: 480 g
Net width: 46 mm
Net height: 139 mm
Net depth: 50 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895350828
Basic packaging weight: 0,52 kg
Basic Packaging Dimensions Height: 0,139 m
Basic Packaging Dimensions Width: 0,07 m
Basic Packaging Dimensions Depth: 0,052 m
Basic packaging volume: 0,001 m³

Transportna embalaža

Transport packaging quantity: 26 pcs
EAN code for a transport packaging: 3838895562412
Transport packaging weight: 13,87 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 1.352 pcs
Customs tariff: 85361090

Rated switching capacity AC: 200 kA
Voltage type: AC
Fuse construction type according to IEC 60269: NH1
Rated voltage AC: 690
Power loss at rated current: 23,8 W
Type of fuse status indicator: Top fuse status indicator
Rated current: 160 A
Utilization category: gR (general purpose semiconductor protection)

ETIM klasifikacija – različica 9.0
