NHS3/210-165 UQ1 aR 710A/2000V Talilni vložek

Zaloga status Po naročilu

ETI koda:: 004735166
Tip varovalke:: NH-S
Velikost:: NH3
Nazivni tok:: 710 A
Karakteristika:: aR
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna AC napetost:: 2000 V
AC Izklopna zmogljivost:: 50 kA
Izgubna moč:: 280 W
Talilni Joulov integral (A2s):: 380.000
Skupni Joulov integral (A2s):: 3.200.000
Standardi:: IEC 60269-4
Aplikacije:: Za zaščito polprevodniških naprav

Produkt

Neto teža izdelka: 2.000 g
Net width: 75 mm
Net height: 244 mm
Net depth: 60 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895644644
Basic packaging weight: 2,06 kg
Basic Packaging Dimensions Height: 0,094 m
Basic Packaging Dimensions Width: 0,213 m
Basic Packaging Dimensions Depth: 0,078 m
Basic packaging volume: 0,002 m³

Transportna embalaža

Transport packaging quantity: 9 pcs
EAN code for a transport packaging: 3838895644651
Transport packaging weight: 18,89 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 468 pcs
Customs tariff: 85351000

Rated switching capacity AC: 50 kA
Voltage type: AC
Fuse construction type according to IEC 60269: NH3
Rated voltage AC: 2.000
Power loss at rated current: 280 W
Type of fuse status indicator: Top fuse status indicator
Rated current: 710 A
Utilization category: aR (accompanied semiconductor protection)

ETIM klasifikacija – različica 9.0
