004743219

NH1 UQ02 aR 250A/690V Talilni vložek

Zaloga status V prihodu

ETI koda:: 004743219
Tip varovalke:: NH
Velikost:: NH1
Nazivni tok:: 250 A
Karakteristika:: aR
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna AC napetost:: 690 V
AC Izklopna zmogljivost:: 200 kA
Izgubna moč:: 51 W
Skupni Joulov integral (A2s):: 26.000
Standardi:: IEC 60269-4
Aplikacije:: Za zaščito polprevodniških naprav

Pribor

Produkt

EAN code for a single product: 3838895756545
Neto teža izdelka: 640 g
Net width: 51 mm
Net height: 135 mm
Net depth: 63 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 3 pcs
EAN code for a basic packaging: 3838895399841
Basic packaging weight: 1,996 kg
Basic Packaging Dimensions Height: 0,079 m
Basic Packaging Dimensions Width: 0,17 m
Basic Packaging Dimensions Depth: 0,17 m
Basic packaging volume: 0,002 m³

Transportna embalaža

Transport packaging quantity: 24 pcs
EAN code for a transport packaging: 3838895563181
Transport packaging weight: 16,514 kg
Transport Packaging Dimensions Height: 0,23 m
Transport Packaging Dimensions Width: 0,38 m
Transport Packaging Dimensions Depth: 0,38 m
Transport packaging volume: 0,033 m³
Pallet quantity: 576 pcs
Customs tariff: 85361090

Rated switching capacity AC: 200 kA
Voltage type: AC
Fuse construction type according to IEC 60269: NH1
Rated voltage AC: 690
Power loss at rated current: 51 W
Type of fuse status indicator: Top fuse status indicator
Rated current: 250 A
Utilization category: aR (accompanied semiconductor protection)

ETIM klasifikacija – različica 9.0
