Osv. izbirno stikalo EGS2I-N90-G 004771337
Specifikacija
- Koda izdelka:
- 004771337
- Opis:
- EGS2I-N90-G
- Ime razreda:
- Osv. izbirno stikalo
- Kataloška skupina:
- Tipkala in signalne lučke E-line
- Nazivna AC napetost (V):
- 230V
- type description:
- Selector actuator-symmetric head, 2-position
- Funkcija:
- Osvetljeno tipkalo
Dokumenti
Logistični podatki
Produkt
- EAN koda izdelka
- 3838895808114
- Teža izdelka
- 0.019 kg
- Carinska tarifa
- 85389099
- logis_net_width
- 38 mm
- logis_net_height
- 31 mm
- logis_net_depth
- 47 mm
Osnovno pakiranje
- Količina
- 10
- EAN
- 3838895781134
- Teža
- 0.25 kg
Transportno pakiranje
- Količina
- 140
- EAN
- 3838895781141
- Teža
- 3.5 kg
- Odpremna količina
- 11200
ETIM klasifikacija
- Klasifikacija
- EC000222
- Ime razreda
- Front element for selector switch
- Number of switch positions
- 2
- Type of control element
- Short thumb-grip
- Suitable for illumination
- Da
- Colour control element
- Green
- Colour indicator light cap
- Green
- Hole diameter
- 22,5mm
- Switching function latching
- Da
- Degree of protection (IP), front side
- IP65
