Ločilno stikalo ED2 160/3 004671272
Specifikacija
- Koda izdelka:
- 004671272
- Opis:
- ED2 160/3
- Ime razreda:
- Ločilno stikalo
- Nazivni tok (A):
- 160A
- Število polov:
- 3
- Tip priključitve:
- Sprednji kontakt
- Standardi:
- IEC 60947-3
- Nazivna impulzna vzdržna napetost Uimp (kV):
- 8kV
- Kategorija uporabe:
- AC-23A,DC-22A
- Nazivni kratkostični vklopni tok Icm:
- 6kA
- Nazivni kratkostični vzdržni tok Icw pri 0,3s:
- 3kA
- Nazivna delovna napetost (V AC):
- 690V
- Nazivna napetost (V DC):
- 250V
- Nazivna izolacijska napetost (V):
- 800V
Dokumenti
Logistični podatki
Produkt
- Teža izdelka
- 1.1 kg
- Carinska tarifa
- 85362090
- logis_net_width
- 105 mm
- logis_net_height
- 165 mm
- logis_net_depth
- 92 mm
Transportno pakiranje
- Količina
- 1
- EAN
- 3838895411055
- Teža
- 1.5 kg
- Odpremna količina
- 727
ETIM klasifikacija
- Klasifikacija
- EC000216
- Ime razreda
- Switch disconnector
- Version as main switch
- Da
- Version as maintenance-/service switch
- Da
- Version as safety switch
- Da
- Rated permanent current Iu
- 160A
- Conditioned rated short-circuit current Iq
- 65kA
- Number of poles
- 3
- Motor drive optional
- Da
- Voltage release optional
- Da
- Device construction
- Built-in device fixed built-in technique
- Suitable for floor mounting
- Da
- Type of control element
- Rocker lever
- Type of electrical connection of main circuit
- Screw connection
- Degree of protection (IP), front side
- IP20
