Inštalacijski odklopnik ETIMAT P10 1p D63 001901056
Specifikacija
- Koda izdelka:
- 001901056
- Opis:
- ETIMAT P10 1p D63
- Ime razreda:
- Inštalacijski odklopnik
- Nazivni tok (A):
- 63A
- Izklopna karakteristika:
- D
- Število polov:
- 1
- Nazivna kratkostična zmogljivost (kA):
- 10kA
- Vrsta napetosti:
- AC
- Nazivna AC napetost (V):
- 230V/400V
- Nazivna frekvenca (Hz):
- 50Hz/60Hz
- Nazivna impulzna vzdržna napetost Uimp (kV):
- 6kV
- Nazivni presek:
- 1mm²-25mm²
- Standardi:
- EN/IEC 60898
- Funkcija:
- MCB SLO
Dokumenti
Logistični podatki
Produkt
- EAN koda izdelka
- 3838895973430
- Teža izdelka
- 115 g
- Carinska tarifa
- 85362010
Osnovno pakiranje
- Količina
- 12
- EAN
- 3838895973447
- Teža
- 1.44 kg
Transportno pakiranje
- Količina
- 108
- EAN
- 3838895973454
- Teža
- 13.28 kg
- Odpremna količina
- 5616
ETIM klasifikacija
- Klasifikacija
- EC000042
- Ime razreda
- Miniature circuit breaker (MCB)
- Release characteristic
- D
- Number of poles (total)
- 1
- Number of protected poles
- 1
- Rated current
- 63A
- Rated voltage
- 230/400V
- Rated insulation voltage Ui
- 500V
- Rated impulse withstand voltage Uimp
- 6kV
- Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
- 10kA
- Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
- 10kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
- 10kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
- 10kA
- Voltage type
- AC
- Frequency
- 50…60Hz
- Current limiting class
- 3
- Suitable for flush-mounted installation
- Da
- Over voltage category
- 3
- Pollution degree
- 2
- Additional equipment possible
- Da
- Built-in depth
- 70mm
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -40…70°C
- Connectable conductor cross section multi-wired
- 1…25mm²
- Connectable conductor cross section solid-core
- 1…25mm²
ETIMAT P10 1p D63
