Prenapetostni odvodnik MOD.ETITEC ML T123 305/50 G 002440674
Specifikacija
- Koda izdelka:
- 002440674
- Opis:
- MOD.ETITEC ML T123 305/50 G
- Ime razreda:
- Prenapetostni odvodnik
- Funkcija:
- SPD Modul
- Tip:
- T1, T2, T3
- Za uporabo z:
- ETITEC ML T123
Dokumenti
Logistični podatki
Produkt
- Carinska tarifa
- 85363090
- logis_net_width
- 18 mm
- logis_net_height
- 45 mm
- logis_net_depth
- 64 mm
Osnovno pakiranje
- Količina
- 1
- EAN
- 3838895927303
- Teža
- 0.14 kg
Transportno pakiranje
- Količina
- 28
- EAN
- 3838895927310
- Teža
- 4.001 kg
- Odpremna količina
- 4620
ETIM klasifikacija
- Klasifikacija
- EC001457
- Ime razreda
- Combined arrester for power supply systems
- System configuration DC
- Ne
- System configuration IT
- Ne
- System configuration TN
- Da
- System configuration TN-C
- Da
- System configuration TN-S
- Da
- System configuration TT
- Da
- System configuration other
- Ne
- Number of poles
- 1
- Lightning impulse current (10/350 µs)
- 50
- Max. continuous voltage AC
- 305
- Nominal voltage AC
- 230
- Specific energy (W/R)
- 39
- Mounting method
- On basic element
- Construction size
- 1 modular spacing
- Signalling at the device
- Optical
- Test class
- Type 1 + 2
- Exhausting
- Ne
- Integrated backup fuse
- Ne
- Degree of protection (IP)
- IP20
MOD.ETITEC ML T123 305/50 G
