Prenapetostni odvodnik ETITEC V T12 440/12,5 1+0 002442901
Specifikacija
- Koda izdelka:
- 002442901
- Opis:
- ETITEC V T12 440/12,5 1+0
- Ime razreda:
- Prenapetostni odvodnik
- AC max continous operating voltage Uc:
- 440
- Tip:
- T1, T2
- Maks. odvodni tok (10/350) (kA):
- 12.5
- In (8/20) (kA):
- 20
- Imax(8/20) (kA):
- 50
- Up - Stopnja zaščite (kV):
- 1,7
- Uhajavi tok:
- JA
- Uporabljena tehnologija:
- MOV
- Daljinska signalizacija:
- Ne
- Sistem omrežja:
- IT
- Število modulov:
- 1
- Built-in depth (mm):
- 68
- Funkcija:
- SPD
- Kataloška skupina:
- ETITEC V
Dokumenti
Logistični podatki
Produkt
- Carinska tarifa
- 85354000
- logis_net_width
- 18 mm
- logis_net_height
- 95 mm
- logis_net_depth
- 67 mm
Osnovno pakiranje
- Količina
- 1
- EAN
- 3838895826569
- Teža
- 0.14 kg
Transportno pakiranje
- Količina
- 64
- EAN
- 3838895826576
- Teža
- 10.56 kg
- Odpremna količina
- 2560
COM_ETISTORE_ITEM_TITLE_LOGISTIC_DATA_SECTION4
- qty
- 8 pcs
- Teža
- 1.225 kg
- Višina (mm)
- 90 mm
- Globina (mm)
- 183 mm
- volume
- 1.729 dm3
ETIM klasifikacija
- Klasifikacija
- EC001457
- Ime razreda
- Combined arrester for power supply systems
- System configuration DC
- Ne
- System configuration IT
- Da
- System configuration TN
- Da
- System configuration TN-C
- Da
- System configuration TN-S
- Da
- System configuration TT
- Ne
- System configuration other
- Ne
- Number of poles
- 1
- Lightning impulse current (10/350 µs)
- 12,5kA
- Max. continuous voltage AC
- 440V
- Nominal voltage AC
- 400V
- Voltage protection level
- 1,7kV
- Specific energy (W/R)
- 40kJ/Ohm
- Mounting method
- DIN rail (top hat rail) 35 mm
- Remote signalling
- Ne
- Signalling at the device
- Optical
- Test class
- Type 1 + 2
- Integrated backup fuse
- Ne
- Degree of protection (IP)
- IP20
Slike in diagrami
