VVT-D3 7,2kV/6,3A 004222006

Specifikacija

Koda izdelka:
004222006
Opis:
VVT-D3 7,2kV/6,3A
Nazivni minimalni odklopni tok (A):
25
Hladna upornost (mΩ):
260
Nazivni tok (A):
6.3
Tip:
Nova VVT-D 80N s termo sprožnik
Velikost:
192
Karakteristika:
Other
Nazivna AC napetost (V):
7200
Indikator:
Temperature limiter, 80N striker force
AC Izklopna zmogljivost (kA):
63
Izgubna moč (W):
10
Aplikacije:
Zaščita transformatorja, zaščita motorja, zaščita kondenzatorske baterije, vgradnja v obročno glavno enoto

Dokumenti

Produkt

EAN koda izdelka
3838895907657
Teža izdelka
1.2 kg
Carinska tarifa
85351000

Osnovno pakiranje

Osnovno pakiranje
1
EAN koda osnovnega pakiranja
3838895907657
Teža osnovnega pakiranja
1.2 kg
Volumen osnovnega pakiranja
5.14

Transportno pakiranje

Pakirna količina
3
EAN koda odpremnega pakiranja
3838895907664
Teža odpremnega pakiranja
4.22 kg
Volumen pakirne embalaže
15.42
Odpremna količina
180
Volumen paletnega pakiranja
925.2

Slike in diagrami

Programska oprema

Konfigurator Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
004222006Flush mounted enclosureFuse link, VVT-D3 7,2kV/6,3AVVHigh voltage fuse-links7,2 kV192 mm192 mmVVT-DFuse links for medium voltageVVT-DVVT-D3 7,2KV/6,3Rated current 6.3AType NEW VVT-D 80N Thermo strikerSize 192Characteristics OtherRated AC voltage 7200VIndicator Temperature limiter, 80N striker forceBreaking capacity AC 63kAPower dissipation 10WApplication transformer protection, motor protection, capacitor bank protection, installation in ring main unitRated minimum breaking current 25ACold resistance 260mΩFuse link VVT NEW VVT-D 80N Thermo striker 192 6.3A 7200V
