NH3L gR 315A/1100V DC Talilni vložek

Zaloga status Po naročilu

ETI koda:: 004110547
Tip varovalke:: NH
Velikost:: NH3L
Nazivni tok:: 315 A
Karakteristika:: gR
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna enosmerna napetost:: 1100 V
DC Izklopna zmogljivost:: 10 kA
L/R:: 5 ms
Izgubna moč (0,7xIn):: 25,2 W
Izgubna moč:: 54 W
Talilni Joulov integral (A2s):: 166.800
Skupni Joulov integral (A2s):: 221.900
Standardi:: IEC 60269-4
Aplikacije:: Talilni vložki za DC aplikacije

Pribor

Produkt

Neto teža izdelka: 1.500 g
Net width: 65 mm
Net height: 209 mm
Net depth: 83,6 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895603214
Basic packaging weight: 1,56 kg
Basic Packaging Dimensions Height: 0,077 m
Basic Packaging Dimensions Width: 0,224 m
Basic Packaging Dimensions Depth: 0,102 m
Basic packaging volume: 0,002 m³

Transportna embalaža

Transport packaging quantity: 9 pcs
EAN code for a transport packaging: 3838895608820
Transport packaging weight: 14,39 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 468 pcs
Customs tariff: 85351000

Voltage type: DC
Fuse construction type according to IEC 60269: 3L
Power loss at rated current: 54 W
Rated switching capacity DC: 10 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 315 A
Rated voltage DC: 1.100
Utilization category: gR (general purpose semiconductor protection)

ETIM klasifikacija – različica 9.0
