004334211

NH2 UQ gR 125A/690V Talilni vložek

Zaloga status Po naročilu

ETI koda:: 004334211
Tip varovalke:: NH
Velikost:: NH2
Nazivni tok:: 125 A
Karakteristika:: gR
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna AC napetost:: 690 V
AC Izklopna zmogljivost:: 50 kA
DC Izklopna zmogljivost:: 25 kA
Izgubna moč:: 40 W
Skupni Joulov integral (A2s):: 16.000
Standardi:: IEC 60269-4
Aplikacije:: Za zaščito polprevodniških naprav

Pribor

Produkt

EAN code for a single product: 3838895732976
Neto teža izdelka: 660 g
Net width: 57,5 mm
Net height: 152 mm
Net depth: 70 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 3 pcs
EAN code for a basic packaging: 3838895009801
Basic packaging weight: 2,024 kg
Basic Packaging Dimensions Height: 0,078 m
Basic Packaging Dimensions Width: 0,169 m
Basic Packaging Dimensions Depth: 0,153 m
Basic packaging volume: 0,002 m³

Transportna embalaža

Transport packaging quantity: 15 pcs
EAN code for a transport packaging: 3838895161042
Transport packaging weight: 10,468 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 780 pcs
Customs tariff: 85361090

Rated switching capacity AC: 50 kA
Voltage type: AC
Fuse construction type according to IEC 60269: NH2
Rated voltage AC: 690
Power loss at rated current: 40 W
Rated switching capacity DC: 25 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 125 A
Utilization category: gR (general purpose semiconductor protection)

ETIM klasifikacija – različica 9.0

Eplan

Programska oprema je zagotovljena takšna, kot je, brez kakršnihkoli jamstev ali garancij. Avtor ni zavezan zagotavljati podpore, storitev, popravkov ali nadgradenj brezplačnim programom ali gonilnikom.

Pribor 45 Ves pribor

001691022

VL2 M12

001691029

VL2 M12x35

001691030

VL2 SP.240 P

001691031

VL2 SP.300

001692000

SL2 3P SP.300

001692210

SL2 1P M12

001692211

SL2 1P SP.300

001692212

SL2 1P SP.240

001692230

SL2 3P M12

001692231

SL2 3P SP.240

001693020

SL2 3P M12 400/5 KI.1

001693060
