004335215

NH3 UQ aR 560A/690V Talilni vložek

Zaloga status Po naročilu

ETI koda:: 004335215
Tip varovalke:: NH
Velikost:: NH3
Nazivni tok:: 560 A
Karakteristika:: aR
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna AC napetost:: 690 V
AC Izklopna zmogljivost:: 50 kA
DC Izklopna zmogljivost:: 25 kA
Izgubna moč:: 135 W
Skupni Joulov integral (A2s):: 730.000
Standardi:: IEC 60269-4
Aplikacije:: Za zaščito polprevodniških naprav

Pribor

Produkt

EAN code for a single product: 3838895733133
Neto teža izdelka: 910 g
Net width: 69 mm
Net height: 150 mm
Net depth: 82 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 3 pcs
EAN code for a basic packaging: 3838895010043
Basic packaging weight: 2,85 kg
Basic Packaging Dimensions Height: 0,088 m
Basic Packaging Dimensions Width: 0,213 m
Basic Packaging Dimensions Depth: 0,163 m
Basic packaging volume: 0,003 m³

Transportna embalaža

Transport packaging quantity: 12 pcs
EAN code for a transport packaging: 3838895161219
Transport packaging weight: 11,75 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 624 pcs
Customs tariff: 85361090

Rated switching capacity AC: 50 kA
Voltage type: AC
Fuse construction type according to IEC 60269: NH3
Rated voltage AC: 690
Power loss at rated current: 135 W
Rated switching capacity DC: 25 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 560 A
Utilization category: aR (accompanied semiconductor protection)

ETIM klasifikacija – različica 9.0
