NH3L UQ2 aR 500A/1200V Talilni vložek

Zaloga status Po naročilu

ETI koda:: 004734226
Tip varovalke:: NH
Velikost:: NH3L
Nazivni tok:: 500 A
Karakteristika:: aR
Indikator:: Indikator stanja zgornjega talilnega vložka
Nazivna AC napetost:: 1200 V
AC Izklopna zmogljivost:: 200 kA
Izgubna moč:: 185 W
Skupni Joulov integral (A2s):: 320.000
Standardi:: IEC 60269-4
Aplikacije:: Za zaščito polprevodniških naprav

Pribor

Produkt

Neto teža izdelka: 1.500 g
Net width: 65 mm
Net height: 209 mm
Net depth: 83,6 mm
Stock unit of measure: pcs

Osnovna embalaža

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895351337
Basic packaging weight: 1,56 kg
Basic Packaging Dimensions Height: 0,077 m
Basic Packaging Dimensions Width: 0,224 m
Basic Packaging Dimensions Depth: 0,102 m
Basic packaging volume: 0,002 m³

Transportna embalaža

Transport packaging quantity: 9 pcs
EAN code for a transport packaging: 3838895562962
Transport packaging weight: 14,39 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 468 pcs
Customs tariff: 85351000

Rated switching capacity AC: 200 kA
Voltage type: AC
Fuse construction type according to IEC 60269: 3L
Rated voltage AC: 1.200
Power loss at rated current: 185 W
Type of fuse status indicator: Top fuse status indicator
Rated current: 500 A
Utilization category: aR (accompanied semiconductor protection)
